LINK E-Throttle Accelerator Pedal Module (PED) for Drive-by-Wire Systems

Description

Details

E-Throttle Accelerator Pedal Module

• Firewall mounted hanging design
• 16degree (~70mm) travel
• Redundant dual output potentiometers suitable for use with Electronic throttle bodies
• Includes 6 pin mating connector kit

Technical Specs:
See attached image.
Further details on E-Throttle setup can be found in the PC Link helpfile.

Specifications

Pin 1 = 5V Pin 2 = 5V Pin 3 = Sensor Ground Pin 4 = AP Main Output Pin 5 = Sensor Ground Pin 6 = AP Sec Output
